Burner is supplied with snorkel outlet to ensure clean combustion air through connection with external air aspiration duct

The new heat exchanger combined with the new high-performance fans allow for heat output of 92 / 93%

Before heating and after cooling of combustion chamber

Panel with reinforcement cross pleats to ensure superior rigidity and strenght (SP 110-235)

Thermostat: FAN for fan control; LIMIT: for burner control; OVERHEATING: safety thermostat in case of overheating, with manual reset

Bearing structure with removable panels for internal washing, even on hanging machines

All installation inserts and screws are exclusively metric, not self-tapping

Ventilator (IP 55):

- very low noise fan (noise level ≤ 69db at 2 meters)

- high output, high performance fan guarantees increased air flow and static pressure (500 Pa) for uniform and long distance diffusion of warm air through channels or ducts

- fan anchorage on machine’s bearing structure through sturdy rods

- adjustable fresh air re-uptake shutter (SP 110-235)

Control rear electrical panel (IP 65):

- can be connected to thermostat/humidistat/timer

- Integrated in the bottom side
