• Base adapted for moving with a fork lift
• Front protective casing with lockable door for burner cover
• Rear protective casing for the centrifugal fan with air intake/aspiration side joint
• Protective base for the upper part with lifting/fastening hooks
• Central lifting hook
• Removable panels for internal washing with reinforcement cross folds to ensure more rigidity and strength
• Exclusive use of metric screws and inserts for fastening, no self-tapping screws
• The new heat exchanger combined with the new higher performance fans, achieve a thermal output of 96%
• Fan protection IP55:

- very silent (noise level ≤ 69 db at 2 meters);
- high output and performances which ensure high air delivery and static pressure (500 Pa) for uniform diffusion and through long distances of warm air through canals or ducts;
- fan anchored to weight-bearing structure through sturdy
beams and fastening brackets;
- adjustable shutter for fresh air restoration;

• Rear electric control panel (IP65):

- situated at the rear of the machine to avoid contact with
dust, water, snow, etc…
- supplied with a sturdy metal cover which can also be used
to stow tools and documents;

• Front service control panel (IP 65):

- situated at the front of the machine, inside the burner cover casing: to avoid contact with dust, water, snow; for easier maintenance; for more convenient control and intervention operations
